Kirish
This manual provides detailed instructions for the proper use and care of your Swiss Eagle SE-9065-06 Herzog Analog Display Swiss Quartz Watch. This timepiece features a Swiss-made quartz chronograph movement, three sub-dials, a date window, and is designed for durability with a marine-grade stainless steel case and K1 hardened mineral crystal lens.
Figure 1: Swiss Eagle SE-9065-06 Herzog watch worn on a wrist, showcasing uning dizayni va o'lchami.
Sozlash; o'rnatish
Qutini ochish va dastlabki tekshirish
Upon receiving your watch, carefully remove it from its packaging. Inspect the watch for any visible damage. The watch comes in a protective box.
Figure 2: The Swiss Eagle watch presented in its black and red branded box.
Vaqt va sanani o'rnatish
- Tojni oching: The watch features a screw-lock crown. Gently unscrew the crown counter-clockwise until it springs out to position 1.
- Set the Date (Position 2): Pull the crown out further to position 2. Turn the crown clockwise or counter-clockwise to adjust the date. Avoid setting the date between 9 PM and 3 AM, as this can interfere with the automatic date change mechanism. Push the crown back to position 1.
- Set the Time (Position 3): Pull the crown out to position 3. Turn the crown to set the hour and minute hands. To ensure accurate time setting, synchronize with a reliable time source.
- Tojni mahkamlang: Once the time and date are set, push the crown back to position 1 and screw it clockwise firmly against the case to ensure water resistance.
3-rasm: Batafsil view of the watch crown and pushers, essential for time and date adjustments.
Xronograf bilan ishlash
Your Swiss Eagle SE-9065-06 watch is equipped with a chronograph function for measuring elapsed time. It features three sub-dials.
- Boshlash: Press the upper pusher (A) to start the chronograph. The large second hand will begin to move, along with the sub-dial hands.
- To'xta: Press the upper pusher (A) again to stop the chronograph. The elapsed time will be indicated by the main chronograph second hand and the sub-dials.
- Qayta o'rnatish: Xronografni to'xtatgandan so'ng, barcha xronograf strelkalarini nol holatiga qaytarish uchun pastki itarish moslamasini (B) bosing.
Eslatma: Ensure the crown is fully screwed in before using the chronograph, especially in wet conditions, to maintain water resistance.
Xizmat
Soatingizni tozalash
Soatingizning ko'rinishini saqlab qolish uchun korpus va tasmani muntazam ravishda yumshoq, quruq mato bilan artib oling. Silikon tasmalari uchun, reklamaamp cloth with mild soap can be used, followed by a dry cloth. Avoid using harsh chemicals or abrasive materials.
Suvga chidamlilik
This watch is water resistant to 300 meters (330 feet). This makes it suitable for swimming, snorkeling, and recreational diving. However, it is crucial to ensure the screw-lock crown is fully tightened before any exposure to water. Do not operate the crown or pushers while the watch is submerged or wet.
Batareyani almashtirish
The watch is powered by a product-specific battery. When the battery needs replacement, it is recommended to take your watch to an authorized service center or a qualified watchmaker to ensure proper sealing and water resistance are maintained.
Muammolarni bartaraf qilish; nosozliklarni TUZATISH
- Ishlamaydigan tomosha: Soat toji to'liq ichkariga bosilganligini tekshiring. Agar soat hali ham ishlamasa, batareyani almashtirish kerak bo'lishi mumkin.
- Sana o'zgarmaydi: Ensure the time is set correctly, passing midnight. If the date changes at noon, it means the watch is set for PM instead of AM. Adjust the time by 12 hours.
- Xronograf qo'llari nolga qaytmayapti: This may require a chronograph reset procedure. Consult a qualified watchmaker if the issue persists after attempting to reset using the pushers.
- Suv ichidagi kuzatuv: If you notice condensation or water inside the watch, immediately take it to a service center. This indicates a breach in water resistance.
Texnik xususiyatlari
| Xususiyat | Tafsilot |
|---|---|
| Model raqami | SE-9065-06 |
| Harakat turi | Shveytsariya kvarts xronografi |
| Displey turi | Analog |
| Ish materiali | Zanglamaydigan po'lat |
| Koson diametri | 45 mm |
| Koson qalinligi | 13 mm |
| Band materiali | Silikon |
| Band kengligi | 24 mm |
| Kristalli material | K1 Hardened Mineral |
| Suvga chidamlilik chuqurligi | 300 metr (330 fut) |
| Maxsus xususiyatlar | Chronograph, Date Display, Glow In The Dark, Screw-Lock Crown |
| Element og'irligi | 318 gr |
Figure 4: Watch size guide illustrating different case diameters for reference.
Kafolat va qo'llab-quvvatlash
For warranty information and support, please contact the seller of record. Keep your purchase receipt as proof of purchase. For general inquiries about Swiss Eagle products, you may visit the official Swiss Eagle store page.
