Vivitar VIV-PG-D7000 Power Grip Instruction Manual

1. Kirish

The Vivitar VIV-PG-D7000 Power Grip is designed to enhance the functionality and handling of your Nikon D7000 Digital SLR camera. This accessory provides extended battery life, improved stability, and a comfortable vertical shooting experience. It accommodates either two EN-EL15 lithium-ion batteries or six AA batteries, effectively doubling your camera's operational time. The integrated vertical shutter release button and control dials facilitate seamless vertical photography.

2. Paket tarkibi

Paketingizda barcha narsalar mavjudligini tekshiring:

• Vivitar VIV-PG-D7000 Power Grip
• Battery Holder for two EN-EL15 batteries
• Battery Holder for six AA batteries
• Himoya qopqog'i

3. Sozlash

3.1 Batareyani o'rnatish

1. Kamerangiz o'chirilganligiga ishonch hosil qiling.
2. Open the battery compartment of the power grip.
3. Select the appropriate battery holder (for EN-EL15 or AA batteries).
4. Insert the batteries into the holder, observing the correct polarity markings.
5. Slide the loaded battery holder into the power grip until it clicks securely into place.
6. Batareya bo'limi qopqog'ini yoping.

3.2 Attaching the Power Grip to Your Camera

1. Kamerangiz o'chirilganligiga ishonch hosil qiling.
2. Remove the battery from your Nikon D7000 camera.
3. Remove the battery compartment cover from your camera and store it safely.
4. Align the power grip's mounting screw with the camera's tripod socket.
5. Insert the power grip's electrical contact into the camera's battery compartment.
6. Tighten the mounting screw on the power grip until it is firmly secured to the camera. Do not overtighten.

Image: The Vivitar VIV-PG-D7000 Power Grip shown attached to a Nikon D7000 camera body, illustrating how it extends the camera's base and provides a vertical grip. The grip features a textured surface for improved handling and a secondary shutter button.

4. Operating the Power Grip

4.1 Vertical Shutter Release

The power grip features a dedicated shutter release button for comfortable vertical shooting. When the grip is attached and the camera is powered on, this button functions identically to the camera's main shutter button. Press halfway to focus, and fully to take a picture.

4.2 Control Dials and Buttons

Depending on the specific model and camera compatibility, the power grip may include additional control dials or buttons that mirror those on the camera body, such as an AE/AF lock button or command dials. Refer to your camera's manual for specific functions of these controls when used with a power grip.

5. Xizmat ko'rsatish

5.1 Tozalash

To clean the power grip, use a soft, dry cloth. For stubborn dirt, a slightly damp cloth can be used, followed by immediate drying. Avoid using strong detergents, solvents, or abrasive materials, as these can damage the grip's finish or electronic components.

5.2 Saqlash

When not in use for extended periods, remove batteries from the power grip to prevent leakage. Store the grip in a cool, dry place, away from direct sunlight and extreme temperatures. Use the provided protective cap to cover the electrical contacts when the grip is detached from the camera.

6. Muammolarni bartaraf qilish; nosozliklarni TUZATISH

• Power Grip Not Functioning:
  Ensure batteries are correctly inserted with proper polarity. Verify that the battery holder is fully seated within the grip. Check that the grip is securely attached to the camera and the electrical contacts are clean and making proper connection. Ensure the camera's battery compartment door is fully closed or the dummy battery is correctly inserted if applicable.
• Vertical Shutter Release Not Working:
  Confirm the camera is powered on. Check if the grip's power switch (if present) is in the 'on' position. Ensure the grip is firmly attached to the camera.
• Camera Not Recognizing Grip:
  Remove and reattach the grip, ensuring a secure connection. Power cycle the camera. Check for any specific camera settings related to external battery grips in your Nikon D7000 manual.

7. Texnik shartlar

8. Kafolat va qo'llab-quvvatlash

This Vivitar product is covered by a limited warranty. For specific warranty terms, duration, and conditions, please refer to the warranty card included with your purchase or visit the official Vivitar website. For technical support, troubleshooting assistance, or service inquiries, please contact Vivitar customer service through their official channels. Keep your proof of purchase for warranty claims.
