1. Kirish
Thank you for choosing the VEVOR 50L Electric Cigar Humidor Cabinet. This manual provides essential information for the proper setup, operation, and maintenance of your humidor to ensure optimal conditions for your cigars. Please read these instructions thoroughly before use and retain them for future reference.
Figure 1: VEVOR 50L Electric Cigar Humidor Cabinet
2. Mahsulot tugadiview
The VEVOR 50L Electric Cigar Humidor Cabinet is designed to provide a stable and controlled environment for cigar storage, featuring advanced cooling and humidity regulation.
Asosiy xususiyatlar:
- One-Touch Settings: Equipped with a touch-control display panel for effortless adjustment of temperature and humidity.
- Constant Temperature & Humidity: Utilizes a circulating water tank, high-performance compressor, and circulating fan for even air distribution.
- Katta sig'im: Crafted from 100% Spanish cedar, offering dual-layer storage for up to 300 cigars (actual capacity may vary by size).
- Transparent Dual-Pane Glass: Double-layer tempered glass provides insulation, heat resistance, and UV protection, while allowing clear visibility.
- Ammonia Reduction: Designed to preserve the flavor and aroma of your cigars by reducing ammonia.
- Mechanical Security Door Lock: Ensures secure storage of your cigar collection.
- Yumshoq LED yoritish: Interior lighting for easy viewmazmuni.
Figure 2: Touch-control display panel and key features.
Figure 3: Illustration of the constant temperature and humidity control system with compressor, fan, and water tank.
Figure 4: Spanish cedar wood shelves and drawers for optimal cigar aging and aroma.
Figure 5: Diagram illustrating the ammonia reduction process within the humidor.
3. O'rnatish bo'yicha ko'rsatmalar
- Paketdan chiqarish: Carefully remove the humidor from its packaging. Inspect for any damage during transit.
- Joylashtirish: Place the humidor on a flat, stable surface away from direct sunlight, heat sources, or areas with extreme temperature fluctuations. Ensure adequate ventilation around the unit.
- Dastlabki tozalash: Before first use, wipe the interior and Spanish cedar shelves/drawers with a clean, damp cloth (using distilled water only). Allow to air dry completely.
- Humidorni ziravorlash: This crucial step prepares the cedar wood to maintain humidity. Fill the circulating water tank (located at the bottom) with distilled water. Place the tank inside the humidor. Close the door and allow the humidor to stabilize for 3-5 days. Monitor the humidity level using the built-in hygrometer.
- Quvvat ulanishi: Plug the humidor into a grounded AC 115V 60Hz power outlet.
- Sigaralarni yuklash: Once the humidor is seasoned and the humidity has stabilized within the desired range (65-75% RH), you may begin placing your cigars on the shelves and in the drawers.
4. Foydalanish bo'yicha ko'rsatmalar
Boshqaruv paneli:
6-rasm: Batafsil view of the touch-control display panel.
- Quvvat tugmasi: Jihozni yoqadi/o'chiradi.
- Haroratni sozlash tugmalari (yuqoriga/pastga strelkalar): Istalgan haroratni sozlaydi.
- Humidity Adjustment Buttons (Up/Down Arrows): Istalgan namlik darajasini sozlaydi.
- Chiroq tugmasi: Toggles the interior LED lighting on/off.
Setting Temperature and Humidity:
- Press the Power button to turn on the humidor.
- Use the Temperature Up/Down arrows to set your desired temperature between 61–72℉ (16–22℃). The display will flash during adjustment and then set.
- Use the Humidity Up/Down arrows to set your desired humidity level between 65–75% RH. The display will flash during adjustment and then set.
- The humidor will automatically work to maintain the set temperature and humidity.
Ammonia Reduction Cycle:
The humidor automatically runs a 5-minute ammonia removal cycle every 12 hours to maintain optimal cigar quality.
Video namoyishi:
Video 1: A seller-provided video demonstrating the features and operation of an electric cigar humidor cabinet, including temperature and humidity control.
5. Xizmat ko'rsatish
- Doimiy tozalash: Periodically clean the interior of the humidor with a soft, damp cloth and distilled water. Avoid using harsh chemicals or abrasive cleaners.
- Water Tank Refill: Check the water level in the circulating water tank regularly. Refill with distilled water as needed to maintain desired humidity.
- Cedar Wood Care: The Spanish cedar shelves and drawers can be wiped with a damp cloth (distilled water) if needed. Do not soak the wood.
- Eshik muhri: Ensure the door seal is clean and free of debris to maintain an airtight environment.
- Changni tozalash: Dust the exterior of the humidor with a soft, dry cloth.
6. Muammolarni bartaraf qilish; nosozliklarni TUZATISH
| Muammo | Mumkin sabab | Yechim |
|---|---|---|
| Humidor not cooling/heating | Power supply issue; fan/compressor malfunction. | Check power connection. Ensure unit is plugged in. Contact customer support if problem persists. |
| Humidity too low/high | Water tank empty/overfilled; poor door seal; ambient conditions. | Refill/adjust water tank. Check door seal for proper closure. Adjust set humidity. |
| G'ayrioddiy shovqin | Unit not level; fan obstruction. | Ensure humidor is on a level surface. Check for any obstructions around the fan. |
| Displey ishlamayapti | Power supply issue; control panel malfunction. | Check power connection. Contact customer support. |
For issues not listed above, please contact VEVOR customer support.
7. Texnik shartlar
| Xususiyat | Spetsifikatsiya |
|---|---|
| Model raqami | 50 l |
| Mahsulot o'lchamlari | 16.54 x 18.7 x 20.28 dyuym |
| Sof og'irlik | 42.33 funt / 19.2 kg |
| Nominal quvvat | 85 Vt |
| jildtage/Chastotasi | AC 115V 60Hz |
| Haroratni nazorat qilish diapazoni | 61 dan 72 ° F / 16 dan 22 ° S gacha |
| Haroratning aniqligi | ±3.6 °F / ±2 °C |
| Namlikni nazorat qilish diapazoni | 60-80% RH |
| Namlik aniqligi | ±3% |
| Aksessuarlar kiritilgan | 2 x kalitlar, 1 x foydalanuvchi qo'llanmasi |
7-rasm: Batafsil mahsulot spetsifikatsiyasi.
8. Kafolat va qo'llab-quvvatlash
VEVOR products come with a standard warranty. For detailed warranty information, product support, or to report any issues, please refer to the contact information provided in your product packaging or visit the official VEVOR websayt. Kafolat da'volari uchun xarid kvitansiyasini saqlang.
